Panasonic develops stretchable substrate for stretchable and flexible electronics

A novel insulating substrate that can be stretched to 2.5 times the original size and then return to the original form

24 Dec 2015 | Editor

Panasonic Corp has recently announced that the company has developed a soft, flexible, and stretchable polymer substrate film using its proprietary stretchable substrate technology. The Company will also provide a transparent electrode material and conductive paste along with this insulating film.

According to the company this newly developed material is an insulating film material that stretches and returns to its original shape, a feature that is hard to find in conventional flexible materials.

It adapts varying free-form surfaces, substantially reducing existing design constraints. For example, it enables the construction of soft and stretchable electronic devices that are adaptable to a variety of forms, such as of clothing and the body. The newly developed material is deployable in a broad range of applications, from wearable devices to sensors, displays, and robots.

The stretchable substrate film offers the following features developed on the basis of the Company's proprietary stretchable resin technology.

  • Soft and stretchable insulating film material that comes with excellent elasticity
    • Tensile elongation: x 2.5 or more
  • Insulating film material capable of relaxing internal stresses arising from stretch, returning to its original shape, and withstanding repeated use
    • Percentage of stress relaxation: 60%
    • Recovery rate: 98% or more
  • Additional development of a stretchable transparent electrode material and conductive paste along with the insulating material
Panasonic - Stretchable substrate

Figure: Panasonic - Stretchable substrate

Panasonic will be exhibiting the stretchable substrate at the forthcoming 17th Printed Wiring Boards Expo held from January 13 to 15, 2016 at Tokyo Big Sight.

www.panasonic.com


About Panasonic

Panasonic Corporation is a worldwide leader in the development of diverse electronics technologies and solutions for customers in the consumer electronics, housing, automotive, enterprise solutions, and device industries.

Since its founding in 1918, the company has expanded globally and now operates 468 subsidiaries and 94 associated companies worldwide, recording consolidated net sales of 7.715 trillion yen for the year ended March 31, 2015. Committed to pursuing new value through innovation across divisional lines, the company uses its technologies to create a better life and a better world for its customers.

Source: Panasonic
